2000RPM High Speed Fiber Optical Slip Ring Miniature Single Channel Compact Size

Brand Name : CENO

Model Number : FCN01G-6

Certification : CE,RoHS,ISO9001

Place of Origin : China

MOQ : 1pcs

Price : Negotiable

Payment Terms : T/T,Paypal,Western Union, L/C

Supply Ability : 500pcs per month

Delivery Time : 1 week

Packaging Details : Standard

Fiber Channel : 1

Return loss : ≥30dB

Speed : 2000rpm max

Wavelength range : 650~1650nm

Sealing grade : IP54 (optional IP65)

Fiber type : SM/MM

Contact Now

2000RPM High Speed Miniature Single Channel Fiber Optical Slip Ring

The miniature single-channel fiber optical slip ring, with a mounting diameter of only 6.8mm, compact size and is especially suitable for installations where the space is small.Single or multimode fiber can be selected. It not only has good optical performance, but also waterproof and dustproof ,transmit signal via fiber optic,no disclose,no EMI and high speed reliable operation.This product is one of the standard products, long-term material preparation, support for fast delivery.

Features

  • Apply to single mode or multi mode photoelectric rotary connection
  • Transmit signal via fiber optic,no disclose,no EMI
  • Convenient to integrate power slip ring

Applications

  • Radar system
  • Medical equipment
  • Military equipment

Optional

  • Fiber channel number
  • Connector type
  • Fiber type
  • Fiber length

Specification

FCN01G-6 Picture
Fiber type SM/MM 2000RPM High Speed Fiber Optical Slip Ring Miniature Single Channel Compact Size
Fiber channel 1
Wavelength range 650~1650nm
Return loss ≥30dB
Insertion loss,max <1.5dB
Rotation speed,max 2000rpm
Operation temperature -20℃~+60℃
Weight 15g
IP grade IP54
Power handing peak ≤23dBm

Outline drawing

2000RPM High Speed Fiber Optical Slip Ring Miniature Single Channel Compact Size

Why with CENO

CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.

Certification

ISO9001,CE,RoHS,UL,Explosion-proof

2000RPM High Speed Fiber Optical Slip Ring Miniature Single Channel Compact Size

CENO Advantage

Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.

Service CENO provides

24 hours,7days consultant service.

Mass and customized production.

Solution offerring for 360° rotation system.

Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
